Technical Specifications
Light Sources
•LED: 1pc 100W COB LED Lamps
•Lifespan: 500,000h
•Color: CW, WW optional
Optics
•Beam angle: 15-60degree
•Dimmer: 0-100% linear dimmer
Light Output
•Luminous flux: 3810 CRI: Ra>95/97
•Illuminance: 678 Lux (6m 15°)
•Optimal projection distance: 5-15m
Control
•Control mode: DMX-512; Auto run
•DMX channel: 1CH, 2CH
•Display of control panel: LCD display + 4 buttons
Power Supply
•Related voltage: AC100V-240V, 50/60Hz
•Related power: 150W
Construction
•Body dimension: D455*W265*H292mm
•Net weight: 8.5kg
•Shell color: black
•Shell material: aluminium die casting
Working Environment
•Working temperature: -25-40℃
•Cooling: Radiator, no fan
•Protection rating: IP20
Standard Configuration Spare Part List
•1pc power cable with plug(America standard, Euro standard, or other standard)
•User manual: English version user manual
Package
•Carton board package size: 530*330*390mm(1pc/carton) [c: 19-09-29]
•N.W/G.W/V.W: 8.0kg/8.1kg/13.7kg
